SKU 90150

King Pin Press

$1,849.99 USD

Components / Adapters

King pins can now be removed in minutes with relative ease and efficiency.

  • Capable of generating 46,000 lbs of force yet weighs only 30 lbs
  • Anti-torque arms prevent twisting of the main body while under extreme force
  • Engineered for use with up to a 1” impact tool

Our heavy-duty King Pin Press was designed with a goal in mind: build the best king pin press possible that requires only one operator to use. We’ve optimized the end plates, manufacturing them out of high-grade steel into diamond shapes – drastically reducing the overall mass of the tool. Coming in at 75% less weight than our closest competitor, the results are huge savings in the tool’s overall weight.

Our King Pin Press includes three different forcing screw options, giving you the ability to service everything from 3/4 ton pickups up to Class 8 trucks. A shortened 1 1/4” forcing screw allows you to access king pins from the hardest to reach places and tightest wheel wells – even on busses. We’ve also included our three most popular tie rod end removers: 7/8”, 3/4”, and 20mm.

• Commonly found on class 3-8 trucks and equipment. (Ram 3500/5500, Chevrolet 3500/5500, Ford F-350/550, Isuzu NPR, Kenworth, Peterbilt, Freightliner, Mack, Volvo, etc.)
• Straight and tapered king pins from 7/8” to 2 5/32”.
Optionally, you can service Isuzu NPR & GMC/Chevrolet W-series trucks with the 90151 Adapter
Optionally, you can remove 2 1/2” King Pins with the 90153 Clearance Plate Adapter.

• Not compatible with FL981 axles where the tie rod is cast to the spindle

U.S. Patent No. 9511488


What type of trucks can I use this tool on?
The tool is designed for straight and tapered king pins from 7/8” to 2 5/32” commonly found on class 3 – 8 trucks (Isuzu NPR, Chevrolet 3500/5500, Ford F-350/550, Kenworth, Peterbilt, Freightliner, etc.)

Why doesn’t my 90150 work on Isuzu NPR & GMC/Chevrolet W-series trucks?
We offer an optional Isuzu NPR & GMC/Chevrolet W-series Adapter for customers looking to service these applications. The part number is 90151.

Proposition 65

Warning: This product may expose you to chemicals including Nickel, which are known to the State of California to cause cancer, birth defects or other reproductive harm.

Warranty & Returns

We offer a Limited Lifetime Warranty on casting, two years on machined or threaded parts and one year warranty on hydraulic components.

Our full Warranty Policy

We offer a 60 day money back guarantee should you feel as though the tool is not the right tool for you. Just be sure it's in unused condition and in original packaging.

Start a Warranty & Return Process

One-person Operation

Our King Pin Press comes in at 75% less weight than our closest competitor. This means you can get the job done not only faster but, with less people as well.

Versatility You Need

Coming with three different sized forcing screws and our three most popular tie rod end removers, you’ll be pressing out more pins on more trucks.

Get even more out of your press

Service even more with add-ons that will make your Tiger Tool work even harder. Service everything from straight/tapered pins to W-Series GMC Chevrolet and Isuzu NPRs.

Just scroll up to the Components / Adapters dropdown.

North American

Engineered, manufactured & assembled under one roof.
