Spare Parts
25 Ton Mining Wheel Stud Service Kit
Part Number
50101-30
Number Required
2
Price
$2.84
Description
Dowel Pin
Part Number
50101-15
Number Required
1
Price
$94.11
Description
Left Stud Extractor
Part Number
50101-14
Number Required
1
Price
$88.92
Description
Right Stud Extractor
Part Number
50101-3
Number Required
1
Price
$253.20
Description
Support Right
Part Number
50101-2
Number Required
1
Price
$301.19
Description
Support Left
Part Number
50101-27
Number Required
4
Price
$1.15
Description
Socket Head Cap Screw, 1/2" - 13 x 1.25"
Part Number
50101-24
Number Required
4
Price
$7.73
Description
Socket Head Cap Screw, 3/4" - 10 x 3.25"
Part Number
50101-23
Number Required
1
Price
$76.18
Description
Safety Spring
Part Number
50101-25
Number Required
4
Price
$5.90
Description
3/4" - 10 x 2.75" Socket Head Cap Screw
Part Number
S254
Number Required
1
Price
$1,089.35
Description
25 Ton Cylinder
Part Number
90102-12
Number Required
4
Price
$0.17
Description
Spring Pin
Part Number
50101-39
Number Required
1
Price
$0.74
Description
Set Screw
Part Number
50101-38
Number Required
1
Price
$15.23
Description
1/2" Quick Link
Part Number
50101-35
Number Required
1
Price
$16.69
Description
1/2" - 13 Eye Bolt
Part Number
50101-34
Number Required
2
Price
$0.09
Description
Hex Nut
Part Number
50101-31
Number Required
3
Price
$15.93
Description
Threaded Ball Plunger
Part Number
50101-29
Number Required
8
Price
$0.98
Description
Dowel Pin, 5/16" x 1"
Part Number
50101-28
Number Required
8
Price
$1.12
Description
Flat Head Cap Screw, 10-24 x 1/2"
Part Number
50101-26
Number Required
4
Price
$4.77
Description
Socket Head Cap Screw, 3/4" - 10 x 2"
Part Number
50101-22
Number Required
1
Price
$31.35
Description
Eye Bolt Nut
Part Number
50101-21
Number Required
1
Price
$68.33
Description
Install Tube
Part Number
50101-20
Number Required
1
Price
$46.15
Description
Broken Stud Pusher
Part Number
50101-19
Number Required
2
Price
$55.56
Description
Install Feet
Part Number
50101-18
Number Required
1
Price
$54.73
Description
Stud Pusher
Part Number
50101-17
Number Required
1
Price
$150.39
Description
Large Install Tube
Part Number
50101-16
Number Required
1
Price
$128.62
Description
Stud Socket Large
Part Number
50101-12
Number Required
1
Price
$555.75
Description
Install Anvil
Part Number
50101-11
Number Required
1
Price
$60.04
Description
Stud Socket
Part Number
50101-10
Number Required
1
Price
$78.46
Description
Cylinder Adapter
Part Number
50101-9
Number Required
2
Price
$138.78
Description
Straight Bearing
Part Number
50101-8
Number Required
2
Price
$143.99
Description
C-Bearing
Part Number
50101-7
Number Required
1
Price
$709.42
Description
Plunger
Part Number
50101-6
Number Required
1
Price
$179.05
Description
Guide Plate
Part Number
50101-5
Number Required
1
Price
$777.34
Description
Cylinder Plate
Part Number
50101-4
Number Required
1
Price
$249.27
Description
Side Rail Spacer
Part Number
50101-1
Number Required
2
Price
$711.16
Description
Side Rail
Part Number
10407-4
Number Required
2
Price
$0.81
Description
Washer
